SPMG Indexable U Drill Insert

SPMG Indexable U drill insert is designed for versatile drilling applications across a range of materials including steel, stainless steel, cast iron, and non-ferrous metals. These inserts offer four usable cutting edges, which reduce costs, and are compatible with various holder sizes from 2xD to 4xD. The system features through coolant capabilities for effective heat dissipation and chip evacuation, ensuring optimal drilling performance and tool life

The TG1115 grade insert, featuring a purple color, is designed for a hardness range of P15-P25, M10-M25, and K10-K25, and is enhanced with a PVD coating. This insert is known for its TiAlSiN PVD layer, which gives it a bronze color and is used for processing steel parts. It is particularly effective for working with hard materials, steel, and stainless steel, and is suitable for materials within a hardness range of 28-50 degrees. The TiAlSiN coating offers excellent wear resistance and thermal stability, making it an ideal choice for a variety of machining applications.

The TG1225 grade insert, with its gray color, offers a hardness range from P20 to P35, M20 to M35, and K20 to K35, and is equipped with a PVD coating. This insert is crafted from microcrystalline carbide that has been optimized for enhanced wear resistance and toughness. It features a nanocrystalline TiALSiN coating, which provides a high bonding strength. These combined attributes result in a broad performance spectrum, making it highly suitable for general machining applications on both steel and stainless steel materials.
